Canon EF 70-200mm f4 L IS USM
Canon EF 70-200mm f4 L IS USM Specifications and Review
| [Back to full Canon EOS Lens List] | |
| Model | Canon EF 70-200mm f4 L IS USM |
| Link to Current Pricing | EF 70-200mm f4 L IS USM |
Production Dates  |
2006 - current |
| Comments | Baby brother to the 70-200/2.8L IS (II) USM. Smaller, lighter, cheaper and just as sharp (though a stop slower). The optical design is somewhat different from the non-IS version (4 extra elements) and includes 1 Fluorite and 2 UD elements. A very good lens, made even more useful by its ability to take the Canon 1.4x and 2x TCs. AF is maintained on all DSLRs with the 1.4x, but only the 1D series bodies can AF (using the center AF zone) with the 2x. IS is also maintained when TCs are used. |
| Field of View
(degrees) Horizontal,Vertical, Diagonal Full Frame - 36x24mm APS-C - 22.5x15mm |
Full Frame Wide : H - 28.8 : V - 19.5 : D - 34.4 Full Frame Tele : H - 10.3 : V - 6.9 : D - 12.3 APS-C Wide : H - 18.3 : V - 12.2 : D - 21.9 APS-C Tele : H - 6.4 : V - 4.3 : D - 7.7 |
| Full Frame FOV equivalent with lens on APS-C body |
112-320 mm (1.6x multiplier) |
| Full Frame FOV equivalent with lens on APS-H body |
91-260 mm (1.3x multiplier) |
| Image Stabilization |
up to 4 stops |
| IS Panning Mode |
Manual Selection |
| Length | 172 mm (6.77 inches) |
| Weight | 760 gm (25.7 oz.) |
| Maximum Diameter | 76 mm (2.99 inches) |
| Lens Mount Material |
Metal |
| Lens Color |
White |
| Filter Size | 67 mm |
| Filter Rotation |
Filter does not rotate |
| Internal Zooming |
Yes (length stays constant) |
| Focusing |
Internal Focusing (Length constant) |
| Focus Range Setting(s) |
Yes, has selectable focus range(s) |
| AF motor |
USM |
| Distance Scale | Yes, has distance scale |
| Closest Focus | 1.2 m (3.94 ft) |
| Maximum Magnification | 0.21x |
| Canon TC compatibility |
Yes, Canon TCs can be used |
| Weathersealing |
Weathersealed |
| Lens Hood |
ET-74 |
| Tripod Mount |
Tripod Mount Ring A |
| E-TTL II Support |
Yes |
| Elements/Groups |
20/15 |
| Special Glass Elements |
Yes, 1 Fluorite element, 2 UD elements |
| Diaphragm Blades |
8 |
|
Check Current Pricing and Availability at Amazon.com |
|
| |
| [Back to full Canon EOS Lens List] | |
With the large number of entries contained in the Canon EOS Lens database it's inevitable the some of presented here may not be complete and/or may contain errors. If you find an error or missing data, please contact me and I will add or revise the data as necessary
