Canon EF 70-300mm f4.5-5.6 DO IS USM
Canon EF 70-300mm f4.5-5.6 DO IS USM Specifications and Review
| [Back to full Canon EOS Lens List] | |
| Model | Canon EF 70-300mm f4.5-5.6 DO IS USM |
| Link to Current Pricing | EF 70-300mm f4.5-5.6 DO IS USM |
Production Dates  |
2004 - current |
| Comments | Canon's second diffractive optics (DO) lens. The use of DO means the lens can be shorter than would be possible using conventional optics. However the EF70-300/4-5.6IS USM is less than half the price and is also pretty sharp. The advantages of the DO lens are size and the fact that it has a true ring USM motor with FT-M focusing, so focus is faster and quieter than the 70-300IS (which uses a micro USM with no FT-M). |
| Field of View
(degrees) Horizontal,Vertical, Diagonal Full Frame - 36x24mm APS-C - 22.5x15mm |
Full Frame Wide : H - 28.8 : V - 19.5 : D - 34.4 Full Frame Tele : H - 6.9 : V - 4.6 : D - 8.3 APS-C Wide : H - 18.3 : V - 12.2 : D - 21.9 APS-C Tele : H - 4.3 : V - 2.9 : D - 5.2 |
| Full Frame FOV equivalent with lens on APS-C body |
112-480 mm (1.6x multiplier) |
| Full Frame FOV equivalent with lens on APS-H body |
91-390 mm (1.3x multiplier) |
| Image Stabilization |
up to 3 stops |
| IS Panning Mode |
Manual Selection |
| IS Tripod Detection |
Automatic |
| Maximum Length | 160 mm (6.3 inches) |
| Minimum Length | 100 mm (3.94 inches) |
| Weight | 720 gm (24.35 oz.) |
| Maximum Diameter | 82 mm (3.23 inches) |
| Lens Mount Material |
Metal |
| Lens Color |
Black |
| Filter Size | 58 mm |
| Filter Rotation |
Filter does not rotate |
| Internal Zooming |
No (extends on zooming) |
| Focusing |
Internal Focusing (Length constant) |
| Focus Range Setting(s) |
No, always uses full focus range |
| AF motor |
USM |
| Distance Scale | Yes, has distance scale |
| Closest Focus | 1.4 m (4.59 ft) |
| Maximum Magnification | 0.19x |
| EF12 magnification range |
0.26x - 0.04x |
| EF25 magnification range |
0.46x - 0.09x |
| Canon TC compatibility |
No, Canon TCs can not be used |
| Weathersealing |
Not weathersealed |
| Lens Hood |
ET-65B |
| E-TTL II Support |
Yes |
| Elements/Groups |
18/12 |
| Aspheric Elements |
Yes, 1 aspheric element |
| Special Glass Elements |
Yes, 1 diffractive element |
| Diaphragm Blades |
6 (circular) |
|
Check Current Pricing and Availability at Amazon.com |
|
| |
| [Back to full Canon EOS Lens List] | |
With the large number of entries contained in the Canon EOS Lens database it's inevitable the some of presented here may not be complete and/or may contain errors. If you find an error or missing data, please contact me and I will add or revise the data as necessary
