Canon EF-S 60mm f2.8 Macro USM
Canon EF-S 60mm f2.8 Macro USM Specifications and Review
| [Back to full Canon EOS Lens List] | |
| Model | Canon EF-S 60mm f2.8 Macro USM |
| Link to Current Pricing | EF-S 60mm f2.8 Macro USM |
Production Dates  |
2005 - current |
| Comments | EF-S Macro lens and the only EF-S prime lens (as of 02/10). Equivalent to 96mm on full frame. Very sharp. Useful as both a macro and a portrait lens. |
| Format Restrictions |
APS-C (crop sensor) only |
| Field of View
(degrees) Horizontal,Vertical, Diagonal Full Frame - 36x24mm APS-C - 22.5x15mm |
APS-C : H - 21.2 : V - 14.3 : D - 25.4 |
| Full Frame FOV equivalent with lens on APS-C body |
96 mm (1.6x multiplier) |
| Length | 70 mm (2.76 inches) |
| Weight | 335 gm (11.33 oz.) |
| Maximum Diameter | 73 mm (2.87 inches) |
| Lens Mount Material |
Metal |
| Lens Color |
Black |
| Filter Size | 52 mm |
| Filter Rotation |
Filter does not rotate |
| Focusing |
Internal Focusing (Length constant) |
| Focus Range Setting(s) |
no information |
| AF motor |
USM |
| Distance Scale | Yes, has distance scale |
| Closest Focus | 0.2 m (0.66 ft) |
| Maximum Magnification | 1x |
| EF12 magnification range |
1.28x - 0.20x |
| EF25 magnification range |
1.61x - 0.44x |
| Canon TC compatibility |
No, Canon TCs can not be used |
| Weathersealing |
Not weathersealed |
| Lens Hood |
ET-67B |
| E-TTL II Support |
Yes |
| Elements/Groups |
12/8 |
| Diaphragm Blades |
7 |
|
Check Current Pricing and Availability at Amazon.com |
|
| |
| [Back to full Canon EOS Lens List] | |
With the large number of entries contained in the Canon EOS Lens database it's inevitable the some of presented here may not be complete and/or may contain errors. If you find an error or missing data, please contact me and I will add or revise the data as necessary
