Canon EF 100mm f2.8 Macro USM
Canon EF 100mm f2.8 Macro USM Specifications and Review
| [Back to full Canon EOS Lens List] | |
| Model | Canon EF 100mm f2.8 Macro USM |
| Link to Current Pricing | EF 100mm f2.8 Macro USM |
Production Dates  |
2000 - 2009 |
| Comments | Very good macro lens at 1/2 the price of the new 100/2.8L IS Macro. If you work from a tripod it might be a better buy (or at least a cheaper one!). Goes to 1:1 magnification, fast and silent USM focus and very sharp indeed. Also quite usable as a portrait lens. A tripod collar is available. Working distance is around 6" at 1:1 |
| Field of View
(degrees) Horizontal,Vertical, Diagonal Full Frame - 36x24mm APS-C - 22.5x15mm |
Full Frame : H - 20.4 : V - 13.7 : D - 24.4 APS-C : H - 12.8 : V - 8.6 : D - 15.4 |
| Full Frame FOV equivalent with lens on APS-C body |
160 mm (1.6x multiplier) |
| Full Frame FOV equivalent with lens on APS-H body |
130 mm (1.3x multiplier) |
| Length | 119 mm (4.69 inches) |
| Weight | 600 gm (20.29 oz.) |
| Maximum Diameter | 79 mm (3.11 inches) |
| Lens Mount Material |
Metal |
| Lens Color |
Black |
| Filter Size | 58 mm |
| Filter Rotation |
Filter does not rotate |
| Focusing |
Internal Focusing (Length constant) |
| Focus Range Setting(s) |
Yes, has selectable focus range(s) |
| AF motor |
USM |
| Distance Scale | Yes, has distance scale |
| Closest Focus | 0.31 m (1.02 ft) |
| Maximum Magnification | 1x |
| Canon TC compatibility |
No, Canon TCs can not be used |
| Weathersealing |
Not weathersealed |
| Lens Hood |
ET-67 |
| Tripod Mount |
Tripod Mount Ring B (adapter required) |
| E-TTL II Support |
Yes |
| Elements/Groups |
12/8 |
| Diaphragm Blades |
8 |
|
Check Current Pricing and Availability at Amazon.com |
|
| |
| [Back to full Canon EOS Lens List] | |
With the large number of entries contained in the Canon EOS Lens database it's inevitable the some of presented here may not be complete and/or may contain errors. If you find an error or missing data, please contact me and I will add or revise the data as necessary
