Canon EF 70-200mm f2.8L IS II USM
Canon EF 70-200mm f2.8L IS II USM Specifications and Review
| [Back to full Canon EOS Lens List] | |
| Model | Canon EF 70-200mm f2.8L IS II USM |
| Link to Current Pricing | EF 70-200mm f2.8L IS II USM |
Production Dates  |
2010 - current |
| Comments | The latest version of Canon's 70-200/2.8 zooms. AF has been speeded up, close focus distance has been decreased (and magnification has been increased). One fluorite element and one more UD element have been added to the design. The IS system has been upgraded to now provide up to 4 stops of stabilization. List price is now $2499 (vs. $1999 for the original version)
Initial user reports are all very positive with the lens being described as "razor sharp" and an improvement over the original version. |
| Field of View
(degrees) Horizontal,Vertical, Diagonal Full Frame - 36x24mm APS-C - 22.5x15mm |
Full Frame Wide : H - 28.8 : V - 19.5 : D - 34.4 Full Frame Tele : H - 10.3 : V - 6.9 : D - 12.3 APS-C Wide : H - 18.3 : V - 12.2 : D - 21.9 APS-C Tele : H - 6.4 : V - 4.3 : D - 7.7 |
| Full Frame FOV equivalent with lens on APS-C body |
112-320 mm (1.6x multiplier) |
| Full Frame FOV equivalent with lens on APS-H body |
91-260 mm (1.3x multiplier) |
| Image Stabilization |
up to 4 stops |
| Length | 199 mm (7.83 inches) |
| Weight | 1490 gm (50.38 oz.) |
| Maximum Diameter | 89 mm (3.5 inches) |
| Lens Mount Material |
Metal |
| Lens Color |
White |
| Filter Size | 77 mm |
| Filter Rotation |
Filter does not rotate |
| Internal Zooming |
Yes (length stays constant) |
| Focusing |
Internal Focusing (Length constant) |
| Focus Range Setting(s) |
Yes, has selectable focus range(s) |
| AF motor |
USM |
| Distance Scale | Yes, has distance scale |
| Closest Focus | 1.2 m (3.94 ft) |
| Maximum Magnification | 0.21x |
| Canon TC compatibility |
Yes, Canon TCs can be used |
| Weathersealing |
Weathersealed |
| Lens Hood |
ET-89 |
| Tripod Mount |
Tripod Mount Ring A |
| E-TTL II Support |
Yes |
| Elements/Groups |
23/19 |
| Special Glass Elements |
Yes, 1 Fluorite element and 5 UD elements |
| Diaphragm Blades |
8 |
|
Check Current Pricing and Availability at Amazon.com |
|
| |
| [Back to full Canon EOS Lens List] | |
With the large number of entries contained in the Canon EOS Lens database it's inevitable the some of presented here may not be complete and/or may contain errors. If you find an error or missing data, please contact me and I will add or revise the data as necessary
