Model | Canon EF 28/2.8 IS USM |
Link to Current Pricing | EF 28/2.8 IS USM |
Production Dates | 2012 - current |
Comments | The EF28/2.8 IS USM is the replacement for the EF 28/2.8. The new lens adds 4 stop image stabilization, a ring USM AF motor with full time manual focus (FT-M) as well as improved coatings. A very good performer with high sharpness and low distortion. Significantly better than the earlier version, but of course more expensive. |
Field of View
(degrees) Horizontal,Vertical, Diagonal Full Frame - 36x24mm APS-C - 22.5x15mm |
Full Frame : H - 65.5 : V - 46.4 : D - 75.4 APS-C : H - 43.8 : V - 30 : D - 51.6 |
Full Frame FOV equivalent with lens on APS-C body |
44.8 mm (1.6x multiplier) |
Full Frame FOV equivalent with lens on APS-H body |
36.4 mm (1.3x multiplier) |
Image Stabilization | up to 4 stops |
Length | 55.7 mm (2.19 inches) |
Weight | 280 gm (9.47 oz.) |
Maximum Diameter | 68.4 mm (2.69 inches) |
Lens Mount Material | Metal |
Lens Color | Black |
Filter Size | 58 mm |
Filter Rotation | Filter does not rotate |
Focusing | Internal Focusing (Length constant) |
Focus Range Setting(s) | No, always uses full focus range |
AF motor | Ring USM |
Distance Scale | Yes, has distance scale |
Closest Focus | 0.2 m (0.66 ft) |
Maximum Magnification | 0.23x |
EF12 magnification range | 0.62-0.43 |
EF25 magnification range | 1.13-0.95 |
Canon TC compatibility | No, Canon TCs can not be used |
Weathersealing | Not weathersealed |
Lens Hood | EW-65B |
E-TTL II Support | Yes |
Elements/Groups | 11/9 |
Diaphragm Blades | 7 (circular) |
Check Current Pricing and Availability at Amazon.com |
|
[Back to full Canon EOS Lens List] |
With the large number of entries contained in the Canon EOS Lens database it's inevitable the some of presented here may not be complete and/or may contain errors. If you find an error or missing data, please contact me and I will add or revise the data as necessary
