Canon EF 24-70mm f/4.0L IS USM
Canon EF 24-70mm f/4.0L IS USM Specifications and Review
| [Back to full Canon EOS Lens List] | |
| Model | Canon EF 24-70mm f/4.0L IS USM |
| Link to Current Pricing | EF 24-70mm f/4.0L IS USM |
Production Dates  |
2012 - current |
| Comments | The EF 24-70/4L IS USM is the "baby brother" of the EF 24-70/2.8L II USM. Though it's a stop slower, it's smaller, lighter, has image stabilization (good for up to 4 stops), plus it can focus to 0.7x and the IS is hybrid IS, designed for better macro stabilization. The EF 24-105/4L IS USM is less expensive, but it's larger, not quite as sharp and lacks macro capability. |
| Field of View
(degrees) Horizontal,Vertical, Diagonal Full Frame - 36x24mm APS-C - 22.5x15mm |
Full Frame : H - 73.7 : V - 53.1 : D - 84.1 APS-C : H - 50.2 : V - 34.7 : D - 58.8 |
| Full Frame FOV equivalent with lens on APS-C body |
38.4 mm (1.6x multiplier) |
| Full Frame FOV equivalent with lens on APS-H body |
31.2 mm (1.3x multiplier) |
| Image Stabilization |
up to 4 stops |
| Length | 94 mm (3.7 inches) |
| Weight | 600 gm (20.29 oz.) |
| Maximum Diameter | 83.8 mm (3.3 inches) |
| Lens Mount Material |
Metal |
| Lens Color |
Black |
| Filter Size | 77 mm |
| Filter Rotation |
Filter does not rotate |
| Focusing |
Internal Focusing (Length constant) |
| Focus Range Setting(s) |
No, always uses full focus range |
| AF motor |
USM |
| Distance Scale | Yes, has distance scale |
| Closest Focus | 0.38 m (1.25 ft) |
| Maximum Magnification | 0.7x |
| Canon TC compatibility |
No, Canon TCs can not be used |
| Weathersealing |
Weathersealed |
| Lens Hood |
EW-83L |
| E-TTL II Support |
Yes |
| Elements/Groups |
15/12 |
| Aspheric Elements |
Yes, 2 aspheric elements |
| Diaphragm Blades |
9 (circular) |
|
Check Current Pricing and Availability at Amazon.com |
|
| |
| [Back to full Canon EOS Lens List] | |
With the large number of entries contained in the Canon EOS Lens database it's inevitable the some of presented here may not be complete and/or may contain errors. If you find an error or missing data, please contact me and I will add or revise the data as necessary
