Canon EF-S 10-22mm f3.5-4.5 USM
Canon EF-S 10-22mm f3.5-4.5 USM Specifications and Review
Brief Review
The EF 10-22/3.5-4.5 is the crop sensor equivalent of a 16-35 zoom on a full frame camera, i.e. it qualifies as a superwide zoom. Optically it's very good and distortion is low for such a superwide zoom. Superwide lenses can be difficult to use effectively, but they have application in "near-far" landscapes with detail in both the foreground and background and for shooting in small indoor spaces where you can't back away from your subject. This would include Real Estate and Car Interior type shots.
Vignetting is fairly noticable with the lens wide open, but it can be easily (and automatically) corrected in DPP if you shoot RAW and it can even be automatically corrected in-camera for JPEGs if you have an EOS body that supports peripheral illumination correction (Digic IV based cameras such as the 50D, 7D, 5D MkII, 1D MkIV). Overall sharpness is good, assisted by the use of three aspherical elements and 1 UD element (almost an "L" series lens forumula!).
The EF-S 10-22 USM pairs well with the EF 24-105/4L IS USM since most people will never miss the "missing" 23mm focal length! Here's a link to a full review of the EF-S 10-22/3.5-4.5 USM
| [Back to full Canon EOS Lens List] | |
| Model | Canon EF-S 10-22mm f3.5-4.5 USM |
| Link to Current Pricing | EF-S 10-22mm f3.5-4.5 USM |
Production Dates  |
2004 - current |
| Comments | Canon's widest lens for crop sensor DSLRs, equivalent to a 16-35 lens on full frame. Low distortion for such a wideangle, along with good sharpness and a USM focus motor make the EF-S 10-22/3.5-4.5 a very good choice for crop sensor camera owners who want to go wide. The 10-22 uses 3 aspheric elements and 1 UD element to minimize aberrations and maximize image quality. A full review of the EF-S 10-22 can be found HERE |
| Format Restrictions |
APS-C (crop sensor) only |
| Field of View
(degrees) Horizontal,Vertical, Diagonal Full Frame - 36x24mm APS-C - 22.5x15mm |
APS-C Wide : H - 96.7 : V - 73.7 : D - 107 APS-C Tele : H - 54.2 : V - 37.7 : D - 63.1 |
| Full Frame FOV equivalent with lens on APS-C body |
16-35.2 mm (1.6x multiplier) |
| Length | 90 mm (3.54 inches) |
| Weight | 385 gm (13.02 oz.) |
| Maximum Diameter | 83 mm (3.27 inches) |
| Lens Mount Material |
Metal |
| Lens Color |
Black |
| Filter Size | 77 mm |
| Filter Rotation |
Filter does not rotate |
| Internal Zooming |
Yes (length stays constant) |
| Focusing |
Internal Focusing (Length constant) |
| Focus Range Setting(s) |
No, always uses full focus range |
| AF motor |
USM |
| Distance Scale | Yes, has distance scale |
| Closest Focus | 0.24 m (0.79 ft) |
| Maximum Magnification | 0.17x |
| EF12 magnification range |
0.77x - 0.58x |
| EF25 magnification range |
1.51x - 1.28x |
| Canon TC compatibility |
No, Canon TCs can not be used |
| Weathersealing |
Not weathersealed |
| Lens Hood |
EW-83E |
| E-TTL II Support |
Yes |
| Elements/Groups |
13/10 |
| Aspheric Elements |
Yes, 3 aspheric elements |
| Special Glass Elements |
Yes, 1 (S-UD) |
| Diaphragm Blades |
6 (circular) |
|
Check Current Pricing and Availability at Amazon.com |
|
| |
| [Back to full Canon EOS Lens List] | |
With the large number of entries contained in the Canon EOS Lens database it's inevitable the some of presented here may not be complete and/or may contain errors. If you find an error or missing data, please contact me and I will add or revise the data as necessary
