Canon EF 24-70mm f2.8 L USM
Canon EF 24-70mm f2.8 L USM Specifications and Review
Brief Review
The 24-70/2.8L is Canon's premium "wide to normal" zoom. It's very popular with wedding professions and photojournalists due to its high image quality and fast aperture. It's an ideal lens for indoor group shots and portraits and it has a circular 8-blade aperture for smoother out of focus backgrounds (better "bokeh"). Build quality is very good as would be expected from an "L" series lens and the USM AF is quite (another plus for weddings) and accurate. I suppose it's one "failing" is perhaps the lack of any Image Stabilization. For that reason, some prefer the similarly priced EF 24-105/4L IS USM which has IS and a wider zoom range but which is a full stop slower. However at comparable (wide) apertures, the 24-70/2.8 shows less vignetting than the 24-105/4 and at wider focal length settings and, at similar wide apertures, the 24-70/2.8 shows a little less chromatic aberration and somewhat sharper edges (full frame).
The 24-70/2.8L USM is weathersealed and is supplied with a lens hood (optimized for full frame of course).
| [Back to full Canon EOS Lens List] | |
| Model | Canon EF 24-70mm f2.8 L USM |
| Link to Current Pricing | EF 24-70mm f2.8 L USM |
Production Dates  |
2002 - current |
| Comments | Premium wide-to-normal zoom. Much used by event and wedding photographers. Fast aperture allows work in low light and can be used to blur backgrounds. Only drawback is the lack of image stabilization. Some prefer the EF24-105/4L IS which although a stop slower does have IS and slightly more reach. |
| Field of View
(degrees) Horizontal,Vertical, Diagonal Full Frame - 36x24mm APS-C - 22.5x15mm |
Full Frame Wide : H - 73.7 : V - 53.1 : D - 84.1 Full Frame Tele : H - 28.8 : V - 19.5 : D - 34.4 APS-C Wide : H - 50.2 : V - 34.7 : D - 58.8 APS-C Tele : H - 18.3 : V - 12.2 : D - 21.9 |
| Full Frame FOV equivalent with lens on APS-C body |
38.4-112 mm (1.6x multiplier) |
| Full Frame FOV equivalent with lens on APS-H body |
31.2-91 mm (1.3x multiplier) |
| Maximum Length | 141 mm (5.55 inches) |
| Minimum Length | 123 mm (4.84 inches) |
| Weight | 950 gm (32.12 oz.) |
| Maximum Diameter | 83 mm (3.27 inches) |
| Lens Mount Material |
Metal |
| Lens Color |
Black |
| Filter Size | 77 mm |
| Filter Rotation |
Filter does not rotate |
| Internal Zooming |
No (extends on zooming) |
| Focusing |
Internal Focusing (Length constant) |
| Focus Range Setting(s) |
No, always uses full focus range |
| AF motor |
USM |
| Distance Scale | Yes, has distance scale |
| Closest Focus | 0.38 m (1.25 ft) |
| Maximum Magnification | 0.29x |
| Canon TC compatibility |
No, Canon TCs can not be used |
| Weathersealing |
Weathersealed |
| Lens Hood |
EW-83F |
| E-TTL II Support |
Yes |
| Elements/Groups |
16/13 |
| Aspheric Elements |
Yes, 2 aspheric elements |
| Special Glass Elements |
Yes, 1 UD element |
| Diaphragm Blades |
8 (circular) |
|
Check Current Pricing and Availability at Amazon.com |
|
| |
| [Back to full Canon EOS Lens List] | |
With the large number of entries contained in the Canon EOS Lens database it's inevitable the some of presented here may not be complete and/or may contain errors. If you find an error or missing data, please contact me and I will add or revise the data as necessary
