Canon EF 24-105mm f4 L IS USM
Canon EF 24-105mm f4 L IS USM Specifications and Review
Brief Review
The EF 24-105/4L IS USM is the standard general puropose "walking around" lens for full frame cameras. It cover the range from wideangle though normal, portrait and short-tele applications with a relatively fast constant f4 aperture and an effective image stabilization system, The EF 24-70/2.8L is faster, but lacks IS and has a shorter telephoto reach, The EF 24-105/4L makes an ideal travel lens for use with a full frame DSLR like the EOS 5D (MkII) since in most situations other than sports and wildlife photography it may be the only lens you need. It's still a great lens on an APS-C DSLR, but it doesn't have a very wide field of view on a crop sensor camera, so needs to be combined with something like the EF 10-22/3.5-4.5 USM if you want wide-angle coverage too.
| [Back to full Canon EOS Lens List] | |
| Model | Canon EF 24-105mm f4 L IS USM |
| Link to Current Pricing | EF 24-105mm f4 L IS USM |
Production Dates  |
2005 - current |
| Comments | Often sold as a high end "kit lens" with the EOS 5D (MkII) DSLR. A very useful focal length range on full frame going from a true wideangle to a short telephoto. Useful for landscapes, travel, portraits and a a general "take everywhere" lens. The IS system is good for at least 3 stops of stabilization. On an APS-C DSLR it's not so wide, but it does match well with the EF-S 10-22 giving high quality coverage from 10mm to 105mm for the pair of lenses. The 24-105/4L IS is the lens that sits on my EOS 5D most of the time. |
| Field of View
(degrees) Horizontal,Vertical, Diagonal Full Frame - 36x24mm APS-C - 22.5x15mm |
Full Frame Wide : H - 73.7 : V - 53.1 : D - 84.1 Full Frame Tele : H - 19.5 : V - 13 : D - 23.3 APS-C Wide : H - 50.2 : V - 34.7 : D - 58.8 APS-C Tele : H - 12.2 : V - 8.2 : D - 14.7 |
| Full Frame FOV equivalent with lens on APS-C body |
38.4-168 mm (1.6x multiplier) |
| Full Frame FOV equivalent with lens on APS-H body |
31.2-136.5 mm (1.3x multiplier) |
| Image Stabilization |
up to 3 stops |
| Length | 107 mm (4.21 inches) |
| Weight | 670 gm (22.66 oz.) |
| Maximum Diameter | 84 mm (3.31 inches) |
| Lens Mount Material |
Metal |
| Lens Color |
Black |
| Filter Size | 77 mm |
| Filter Rotation |
Filter does not rotate |
| Internal Zooming |
No (extends on zooming) |
| Focusing |
Internal Focusing (Length constant) |
| Focus Range Setting(s) |
No, always uses full focus range |
| AF motor |
USM |
| Distance Scale | Yes, has distance scale |
| Closest Focus | 0.45 m (1.48 ft) |
| Maximum Magnification | 0.23x |
| EF12 magnification range |
0.40x - 0.12x |
| EF25 magnification range |
0.61x - 0.27x |
| Canon TC compatibility |
No, Canon TCs can not be used |
| Weathersealing |
Weathersealed |
| Lens Hood |
EW-83H |
| E-TTL II Support |
Yes |
| Elements/Groups |
18/13 |
| Aspheric Elements |
Yes, 3 aspheric elements |
| Special Glass Elements |
Yes, 1 UD element |
| Diaphragm Blades |
8 (circular) |
|
Check Current Pricing and Availability at Amazon.com |
|
| |
| [Back to full Canon EOS Lens List] | |
With the large number of entries contained in the Canon EOS Lens database it's inevitable the some of presented here may not be complete and/or may contain errors. If you find an error or missing data, please contact me and I will add or revise the data as necessary
