Canon EF 28-135mm f3.5-5.6 IS USM
Canon EF 28-135mm f3.5-5.6 IS USM Specifications and Review
| [Back to full Canon EOS Lens List] | |
| Model | Canon EF 28-135mm f3.5-5.6 IS USM |
| Link to Current Pricing | EF 28-135mm f3.5-5.6 IS USM |
Production Dates  |
1998 - current |
| Comments | An early IS lens from Canon. Very useful wide-telephoto zoom range on full frame. Often sold as a "kit lens" with crop sensor bodies such as the EOS 40D and 50D. Not quite so useful on crop sensor DSLRs since it becomes a normal to telphoto zoom rather than a wideangle to telephoto, but the "kit" price is often heavily discounted so it can still be a good purchase. |
| Field of View
(degrees) Horizontal,Vertical, Diagonal Full Frame - 36x24mm APS-C - 22.5x15mm |
Full Frame Wide : H - 65.5 : V - 46.4 : D - 75.4 Full Frame Tele : H - 15.2 : V - 10.2 : D - 18.2 APS-C Wide : H - 43.8 : V - 30 : D - 51.6 APS-C Tele : H - 9.5 : V - 6.4 : D - 11.4 |
| Full Frame FOV equivalent with lens on APS-C body |
44.8-216 mm (1.6x multiplier) |
| Full Frame FOV equivalent with lens on APS-H body |
36.4-175.5 mm (1.3x multiplier) |
| Image Stabilization |
up to 2 stops |
| Maximum Length | 130 mm (5.12 inches) |
| Minimum Length | 97 mm (3.82 inches) |
| Weight | 540 gm (18.26 oz.) |
| Maximum Diameter | 78 mm (3.07 inches) |
| Lens Mount Material |
Metal |
| Lens Color |
Black |
| Filter Size | 72 mm |
| Filter Rotation |
Filter does not rotate |
| Internal Zooming |
No (extends on zooming) |
| Focusing |
Internal Focusing (Length constant) |
| Focus Range Setting(s) |
No, always uses full focus range |
| AF motor |
USM |
| Distance Scale | Yes, has distance scale |
| Closest Focus | 0.5 m (1.64 ft) |
| Maximum Magnification | 0.19x |
| EF12 magnification range |
0.53x - 0.09x |
| EF25 magnification range |
1.03x - 0.21x |
| Canon TC compatibility |
No, Canon TCs can not be used |
| Weathersealing |
Not weathersealed |
| Lens Hood |
EW-78B |
| E-TTL II Support |
Yes |
| Elements/Groups |
16/12 |
| Aspheric Elements |
Yes, 1 aspheric element |
| Diaphragm Blades |
6 |
|
Check Current Pricing and Availability at Amazon.com |
|
| |
| [Back to full Canon EOS Lens List] | |
With the large number of entries contained in the Canon EOS Lens database it's inevitable the some of presented here may not be complete and/or may contain errors. If you find an error or missing data, please contact me and I will add or revise the data as necessary
